Professional custom Stable performance battery energy storage 24v 100ah

stars, based on ( 0 )reviews
$548.00 piece
Quantity Price
1+ $548.00
200+ $520.60
199items available
Contact Us
Product description

Professional custom Stable performance battery energy storage 24v 100ah

China factory High Capacity 24v 100ah lithium battery LiFePO4 battery Deep Cycle
China factory High Capacity 24v 100ah lithium battery LiFePO4 battery Deep Cycle
Weight26kg
Size520*238*228mm/ custom
Working TemperatureCharge -20°C ~ 45°C , 65±20%RH;
Discharge -20°C ~65°C , 65±20%RH
Storage Temperature Less than 1 month -20°C ~ 45°C
less than 3 months -20°C ~ 35°C
Retention of charge(store in one month)above 95%
2. Technical Data
Rated Voltage25.6V
Rated Capacity100Ah
Inner Resistancebelow 50 mΩ
Charge & DischargeWay of chargeCC/CV(Constant Current / Constant Voltage)
Standard Charge Current0.2c (Adjustable)
Max Charge Current1c or customized
Over Charge cut-off voltage29.6v± 0.025V(optional)
Continuous Discharge Current0.5c (Adjustable)
Discharge cut-off voltage20v ± 0.025V(optional)
Peak Discharge Current3c or customized
Cell Over Charge Protection Voltage3.65v ± 0.025V(optional)
Cell Over discharge Protection Voltage2.5v ± 0.025V(optional)


Vglory battery manufacture offers high level safety battery through aseembled with high quality A grade cell . which are good replacing lead-acid batteries in a wide range of applications:

energy storage battery , E-Vehicle battery , motorcycle battery , scooter battery, Ebike battery, Rickshaw battery , AGV battery , etc


Vglory wide range battery has been designed to replace lead-acid batteries , by offering a higher energy density for an equivalent weight and size.


Vglory lithium battery with advantages : the high reliability, lower cost , long lifespan and no pollution operation etc


Advantages of VG Lithium battery :

Many advantages of our Lithium battery such as : long cycle life , Steady performance , wide temperature working range , widely applications , small in volume and light in weight , Safety , No memory effetcs ; etc

Wide range power capacity available:

we can custom battery per clients requirements OEM Voltage , current , size etc

1


Consistency :

Low internal resistance ,Capacity, Voltage, platform time consistency is good ,



2


low self-discharge rate and long cycle life :

                                                                        less than 3%monthly     above 2000 cycle life

3

Powerful Performance:

Outstanding charge & Discharge properties and Storage Capacity ,with powerful output which maximize your electronic appliances performance

4

High Standard Quality

High standard quality



Battery cell sorting Automatic welding

Using imported control IC intellent sorting machine , fileter the voltage, resistance by once computer calculation .

Aluminum holder

Secure keep your battery on the frame , protect the battery to avoid overcharge and over discharge ,short-circuit etc

Protection board

Our IC are grade A level , with the protection of over-current,over-charge,over-discharge,short circuit,over-voltage , etc .

Nicel strap & stand

We use the qualified nickel strap ,which ensure the safety and circle life of battery .

Wire and Plug :

We use the wire & plug meet the standard of Rohs , to ensure the discharge safety and circle life of battery .

Wide Range Applications

E-Mobility : e-bike, e-scooter, e-skateboard, e-motorcycle, e-tricycle/rickshaw, e-golf cart, e-forklift, e-tourist vehicle , cleanness car, tourist car(E-Tour Car),electric bus, electric wheelchairs, ETC .



Take Care of Lithium battery

How to take care of Lithium battery :
1 . Do not throw battery into water ,keep it away from water, salt, acidic , etc.
2 . Do not throw the battery into fire or heat the battery;
3 . Do not reverse the polarity of the battery pack for any reason.
4 . Forbid to connect the positive and negative terminal directly.
5 . Forbid to hammer to trample the battery;
6 . Do not directly solder the battery and pierce the battery with a nail or other sharp objects
7 . Do not disassemble the battery pack without technician’s guide.

8 . Do not transport or store the battery together with metal objects such as hairpins, necklaces, etc.
Company Information

ABOUT US

Vglory battery company is professinal in producing , R&D and marketing in lithium battery field , professional engineer team with above 10years experiences ,

Widely in use for Electric bike,motorcycle,power tools ,energy storage and OEM service, all batteries are manucturing strictly according to ISO ,with advanced equipments and test machine. which garantee

                           the superior quality for our clients,

                       Welcome Contact us ...
Thanks Supports
Place of Origin:
Guangdong, China
Brand Name:
Vglory
Model Number:
BP24V100AH
Capacity:
12v100ah
Battery type:
24v lithium battery pack
Product name:
24v 100ah lithium battery
Material:
Li ion battery cell
Warranty:
2 Year
Charge Current:
0.2C
Discharge Current:
0.5C
Charge Cut-off Voltage:
29.2v
Discharge Cut-off Voltage:
20v
Cycle life:
above 2000cycles
